Volkswagen Transporter T4 Delivery Van
==============================================
1. Main
-
Class:
D Delivery -
Body type:
4-door Van -
Transmision:
4-speed Automatic -
FWD
-
Clutch type:
hydrokinetic -
Length:
4707 mm -
Width:
1840 mm -
Width with side mirrors:
2,175 mm -
Height:
1940 mm -
Wheelbase:
2920 mm -
Track width - front:
1589 mm -
Track width - rear:
1554 mm -
Front overhang:
968 mm -
Rear overhang:
901 mm -
Ground clearance:
180 mm -
Steering system type:
rack and pinion gear with hydraulic booster -
Basic tires:
195/65 R15 -
Optional tires:
205/70 R16; 225/65 R16 -
Type of brakes (front):
ventilated discs -
Type of brakes (rear):
disc -
Diameter of the brake discs (front):
313 mm -
Diameter of the brake discs (rear):
294 mm -
Type of suspension (front):
McPherson strut, lower swing arm, stabilizer -
Suspension type (rear):
torsion beam -
Shock absorbers:
gas -
Number of seats:
2
==============================================
2. Engine
-
Model:
2.5 TDI -
Produced:
from 1998 to 2003 -
Displacement:
2496 cmΒ³ -
Engine type:
diesel -
Engine power:
150 hp (110 kW) at 4000 rpm -
Maximum torque:
310 Nm at 1500 rpm -
Engine assembly:
front, longitudinal -
Top-up:
turbocharger -
Location of the camshaft:
DOHC -
Number of cylinders:
6 -
Cylinder arrangement:
forked -
Number of valves:
24 -
Compression ratio:
20.0: 1 -
Bore Γ piston stroke:
78.3 Γ 86.4 mm -
Injection type:
direct -
Maximum speed:
220 km / h -
(0 - 100km / h):
9.4 seconds -
Engine code:
AXG
