Volkswagen Passat B4 Sedan
––––––––––––––––––––––––––––––––––––––
▶️ 1. Main ◀️
-
Class:
D -
Body type:
4-door Sedan -
Transmision:
5-speed Automatic -
Drivetrain:
FWD -
Length:
4609 mm -
Width:
1715 mm -
Height:
1433 mm -
Wheelbase:
2623 mm -
Wheel track - front:
1405 mm -
Wheel track - rear:
1375 mm -
Basic tires:
185/65 R14 -
Optional tires:
195/60 R14; 205/45 R16; 205/45 R17; 205/50 R15 -
Brake type (front):
disc -
Brake type (rear):
drum -
Own weight:
1295 kg -
Number of seats:
5
––––––––––––––––––––––––––––––––––––––
▶️ 2. Engine ◀️
-
Model:
1.8 -
Produced:
from 1993 to 1997 -
Displacement:
1781 cm³ -
Engine type:
petrol -
Engine power:
90 HP (66 kW) at 5500 rpm -
Maximum torque:
145 Nm at 2500 rpm -
Engine assembly:
at the front, transversely -
Location of the camshaft:
SOHC (OHC) -
Number of cylinders:
4 -
Cylinder arrangement:
inline -
Number of valves:
8 -
Compression ratio:
10.0 : 1 -
Bore x Stroke :
81 × 86.4 mm -
Injection type:
single-point (SPI, CPI) -
Maximum speed:
178 km/h -
(0 - 100km/h):
14.4 seconds -
Engine code:
ADZ
