Volkswagen Golf MK4 Variant
––––––––––––––––––––––––––––––––––––––
▶️ 1. Main ◀️
-
Class:
C -
Body type:
5-door Wagon -
Transmision:
5-speed Automatic -
Drivetrain:
FWD -
Length:
4397 mm -
Width:
1735 mm -
Height:
1473 mm -
Height with roof rails:
1485 mm -
Wheelbase:
2515 mm -
Track width - front:
1513 mm -
Track width - rear:
1494 mm -
Clearance:
130 mm -
Distance of the front backrest from the engine compartment:
880 mm -
Distance from the front seat to the roof:
979 mm -
Distance between front and rear seats:
590 mm -
Distance from rear seat to roof:
964 mm -
Base tires:
195/65 R15 -
Basic rims:
6J x 15 -
Type of brakes (front):
ventilated discs -
Type of brakes (rear):
disc -
Own weight:
1321 kg -
Number of seats:
5 -
Euro NCAP test:
4/5
––––––––––––––––––––––––––––––––––––––
▶️ 2. Engine ◀️
-
Model:
1.9 TDI -
Produced:
from 2000 to 2006 -
Displacement:
1896 cm³ -
Engine type:
diesel -
Engine power:
100 hp (74 kW) at 4000 rpm -
Maximum Torque:
240 Nm at 1800 rpm -
Engine assembly:
at the front, transversely -
Top up:
turbochargers -
Location of the camshaft:
SOHC (OHC) -
Number of cylinders:
4 -
Cylinder arrangement:
inline -
Number of valves:
8 -
Compression ratio:
19.0:1 -
Bore × stroke:
79.5 × 95.5 mm -
Injection type:
direct -
Maximum speed:
188 km/h -
(0 - 100km/h):
12.5 seconds -
Engine code:
ATD
