🇵🇱 Star 266 Cherry picker (1973 - 2000)

[𝚂𝚝𝚒𝚕𝚕𝙶𝚎𝚝𝚝]

Star 266 Cherry picker

–––––––––––––––––––––––––––––––––––

▶️ 1. Main ◀️

• Class: medium-duty off-road truck

• Transmision: 5-speed automatic

• Gearbox name: S5-45

• Drivetrain: 6x6

• Length: 6820 mm

• Width: 2500 mm

• Height: 2660 mm

• Wheelbase: 2970+1250 mm

• Ground clearance: 780 mm

• Ground clearance: 325 mm

• Approach angle: 37°

• Departure angle: 42.5°

• Tire size: 12.00 R20

• Own weight: 7350 kg

• Number of seats: 2

–––––––––––––––––––––––––––––––––––

▶️ 2. Engine ◀️

• Model: S359

• Displacement: 6840 cm³

• Engine type: 4-stroke diesel

• Engine power: 150 hp at 2800 rpm

• Maximum torque: 432 Nm at 1600 rpm

• Engine mounting: at the front

• Location of the camshaft: OHV

• Number of cylinders: 6

• Cylinder arrangement: inline

• Compression ratio: 17:1

• Bore × stroke: 110mm x 120mm

• Injection type: direct

• Maximum speed: 90 km/h

• Engine code: S359
