🇨🇿 Škoda Fabia MK1 Comfort Hatchback before facelift (1999 - 2004)

[𝚂𝚝𝚒𝚕𝚕𝙶𝚎𝚝𝚝]

Škoda Fabia MK1 Comfort Hatchback

––––––––––––––––––––––––––––––––––––

▶️ 1. Main ◀️

• Class: B

• Body type: 5-door hatchback

• Transmision: 5-speed automatic

• Drivetrain: FWD

• Turning diameter: 10.2 m

• Turning radius: 5.1 m

• Length: 3960 mm

• Width: 1646 mm

• Width with side mirrors: 1890 mm

• Height: 1451 mm

• Wheelbase: 2462 mm

• Front wheeltrack: 1408 mm

• Rear wheeltrack: 1424 mm

• Front overhang: 837 mm

• Rear overhang: 671 mm

• Ground clearance: 200 mm

• Steering system type: rack-and-pinion with electro-hydraulic power assist

• Basic tire size: 185/60 R14

• Optional tire size: 185/55 R15

• Rim size: 6J X 14

• Front brake type: disc

• Rear brake type: disc

• 100 - 0 km/h with ABS: 39 meters

• Front brake disc diameter: 256 mm

• Rear brake disc diameter: 232 mm

• Front suspension type: independent, McPherson struts

• Rear suspension type: semi-independent, torsion beam

• Own weight: 1155 kg

• Number of seats: 5

• Euro NCAP test rating: 4/5

––––––––––––––––––––––––––––––––––––

▶️ 2. Engine ◀️

• Model: 1.9 TDI - DI is red

• Produced: from 1999 to 2007

• Displacement: 1896 cm³

• Engine type: 4-stroke diesel

• Engine power: 100 HP (74 kW) at 4000 rpm

• Maximum torque: 240 Nm at 2400 rpm

• Engine mounting: at the front, transverselly

• Top-up: turbocharger

• Position of the camshaft: SOHC

• Number of cylinders: 4

• Cylinder arrangement: inline

• Number of valves: 8

• Compression ratio: 19.0 : 1

• Bore × stroke: 79.5 mm × 95.5 mm

• Injection type: direct

• Ignition type: compression

• Maximum speed: 185 km/h

• 0 - 100 km/h: 11.5 seconds

• Engine code: ATD
