🇪🇸 Seat Terra before facelift (1987 - 1990)

[𝚂𝚝𝚒𝚕𝚕𝙶𝚎𝚝𝚝]

Seat Terra

–––––––––––––––––––––––––––––––––––

▶️ 1. Main ◀️

• Class: C LCV

• Body type: 3-door panelvan

• Transmision: 5-speed automatic

• Drivetrain: FWD

• Length: 3869 mm

• Width: 1490 mm

• Height: 1445 mm

• Wheelbase: 2398 mm

• Front wheeltrack: 1256 mm

• Rear wheeltrack: 1277 mm

• Tire size: 145/80 R13

• Rim size: 4.5J x 13

• Front brake type: disc

• Rear brake type: drum

• Own weight: 835 kg

• Number of seats: 5

–––––––––––––––––––––––––––––––––––

▶️ 2. Engine ◀️

• Model: 0.9

• Produced: from 1987 to 1996

• Displacement: 903 cm³

• Engine type: 4-stroke petrol

• Engine power: 40 hp (29 kW) at 5800 rpm

• Maximum torque: 60 Nm at 3000 rpm

• Engine mounting: at the front, transversselly

• Position of the camshaft: OHV

• Number of cylinders: 4

• Cylinder arrangement: inline

• Number of valves: 8

• Compression ratio: 8.5: 1

• Bore × stroke: 65 mm × 68 mm

• Injection type: Weber 32 ICEV carburetor

• Ignition type: spark

• Maximum: 120 km/h

• 0 - 100 km/h: 27.2 seconds

• Engine code: 09 NCA
