Mercedes-Benz S-class MK2 W126
1. Main
-
Class:
F -
Body type:
4-door Sedan -
Transmision:
4-speed automatic -
RWD
-
Length:
4995 mm -
Width:
1820 mm -
Height:
1436 mm -
Wheelbase:
2935 mm -
Ground clearance:
140 mm -
Front seatback distance from steering wheel:
477 mm -
Distance from front seat to roof:
979 mm -
Distance between front and rear seats:
704 mm -
Distance from the rear seat to the roof:
943 mm -
Width above the armrests at the front:
1432 mm -
Width above the armrests at the rear:
1468 mm -
Width at the height of the front armrests:
1328 mm -
Width at the height of the rear armrests:
1416 mm -
Steering system type:
rack and pinion gear with hydraulic booster -
Basic tires:
215/65 R15 -
Optional tires:
205/65 R15 -
Type of brakes (front):
ventilated discs -
Type of brakes (rear):
disc -
Diameter of the brake discs (front):
300 mm -
Diameter of the brake discs (rear):
279 mm -
Own weight:
1950 kg -
Number of seats:
5
2. Engine
-
Model:
560 SE -
Produced:
from 1985 to 1991 -
Displacement:
5547 cmΒ³ -
Engine type:
petrol -
Engine power:
300 hp (221 kW) at 5,000 rpm -
Maximum torque:
455 Nm at 3750 rpm -
Location of the camshaft:
SOHC (OHC) -
Number of cylinders:
8 -
Cylinder arrangement:
forked -
Number of valves:
16 -
Compression ratio:
10.0: 1 -
Bore Γ piston stroke:
96.5 Γ 94.8 mm -
Ignition:
spark -
Injection type:
multi-point (MPI) -
Maximum speed:
250 km / h -
(0 - 100km / h):
6.7 s -
400 meters from a standing start:
14.9 s -
1000 meters from a standing start:
27.1 p
