Komatsu PC7000-11 2019 (Mining Hydraulic Excavator)
《Front》
《Rear》
Name: Machinator G701P Mining Excavator
Specs:
Operating Weight - Backhoe
1512371 - 1541031 lb
(685999 - 698999 kg)
Operating Weight - Loading Shovel
1525598 lb (691999 kg)
Max Bucket Capacity (SAE heaped) - Backhoe
49.7 yd3 (38 m3)
Bucket Capacity (SAE heaped) - Loading Shovel
49.7 yd3 (38 m3)
Max Digging Depth - Backhoe
27′7″ (8446 mm)
Max Digging Depth - Loading Shovel
10′1″ (3085 mm)
Max Dump Height
35′3″ (10752 mm)
Max Dump Height - Loading Shovel
44‘9“ (13682 mm)
Max Bucket Breakout Force (ISO)
370485 lb (168049 kg)
Max Bucket Breakout Force (SAE) - Loading Shovel
227 U.S. tons (2023 kN)
Max Arm Digging Force (ISO)
331143 lb (150204 kg)
Max Arm Digging Force - Loading Shovel
242 U.S. tons (2151 kN)
Arm Length
36′1″ (11000 mm)
Undercarriage
Track Width
59″ - 75″
(1500 - 1900 mm)
Ground Pressure
30.36 - 38.15 psi
(209.32 - 263.03 kPa)
Travel Speed
1.55 mph (2.5 kmh)
Ground Pressure - Loading Shovel
37.74 psi (260.21 kPa)
Engine
Emission Rating
Tier 4 Final
Make / Model
Komatsu SSDA16V159E-3
Gross Horsepower
1675 HP @1,800 rpm (1250 kW @1,800 rpm)
Fluid Capacities
Engine Lubrication
62 U.S. gal (236 L)
Cooling System
116 U.S. gal (440 L)
Fuel Tank Capacity
3443 U.S. gal (13033 L)
Info from: Komatsu PC7000-11 Specs | SMS Equipment
