🇵🇱 FSO 125p Wagon (1983 - 1991)

[𝚂𝚝𝚒𝚕𝚕𝙶𝚎𝚝𝚝]

FSO 125p Wagon

––––––––––––––––––––––––––––––––––––

▶️ 1. Main ◀️

• Class: D

• Body type: 5-door wagon

• Transmision: 4-speed automatic

• Clutch type: single-disc dry with six springs, mechanically controlled

• Drivetrain: RWD

• Turning diameter: 10.8 m

• Length: 4234 mm

• Width: 1630 mm

• Width with side mirrors: 1685 mm

• Height: 1440 mm

• Wheelbase: 2506 mm

• Front wheeltrack: 1298 mm

• Rear wheeltrack: 1275 mm

• Front overhang: 670 mm

• Rear overhang: 1058 mm

• Ground clearance: 130 mm

• Basic tire size: 165/80 R13

• Optional tire size: 175/80 R13

• Basic rim size: 4.5J x 13

• Optional rim size: 5J x 13

• Front brake type: disc

• Rear brake type: disc

• Brake disc diameter: 227 mm

• Front suspension type: independent, upper and lower Triangular wishbones, coil springs

• Rear suspension type: rigid rear axle, two longitudinal 2-leaf springs

• Shock absorbers type: telescopic

• Own weight: 1035 kg

• Number of places: 5

––––––––––––––––––––––––––––––––––––

▶️ 2. Engine ◀️

• Model: 1.5

• Produced: from 1983 to 1991

• Displacement: 1481 cm³

• Engine type: four-stroke petrol

• Engine power: 75 HP (55 kW) at 5400 rpm

• Maximum torque: 114 Nm at 3200 rpm

• Engine mounting: at the front, longitudinally

• Position of the camshaft: OHV

• Number of cylinders: 4

• Cylinder arrangement: inline

• Number of valves: 8

• Compression ratio: 9.0:1

• Bore x stroke: 77 mm × 79.5 mm

• Injection type: 34 DCHD 16 carburetor

• Ignition type: spark

• Maximum speed: 153 km/h

• 0 - 100 km/h: 22 seconds

• Engine code: 115C.076/52
