Wartburg 1.3 Sedan

––––––––––––––––––––––––––––––––––––––

▶️ 1. Main ◀️

• Class: C

• Body type: 4-door sedan

• Transmision: 4-speed automatic

• Clutch type: single-disc, dry

• Drivetrain: FWD

• Turning diameter: 10.8 m

• Turning radius: 5.4 m

• Length: 4220 mm

• Width: 1645 mm

• Height: 1495 mm

• Wheelbase: 2450 mm

• Front wheeltrack: 1380 mm

• Rear wheeltrack: 1360 mm

• Front overhang: 746 mm

• Ground clearance: 122 mm

• Approach angle: 24.0 °

• Departure angle: 15.0 °

• Basic tire size: 165/80 R13

• Optional tire size: 175/70 R13

• Front brake type: disc

• Rear brake type: drum

• Own weight: 900 kg

• Number of seats: 5

––––––––––––––––––––––––––––––––––––––

▶️ 2. Engine ◀️

• Model: 1.3

• Produced: from 1988 to 1991

• Displacement: 1272 cm³

• Engine type: 4-stroke petrol

• Cooling: water

• Engine power: 58 hp (42.5 kW) at 5400 rpm

• Maximum torque: 96 Nm at 3500 rpm

• Engine mounting: at the front, longitudinally

• Position of the camshaft: SOHC

• Number of cylinders: 4

• Cylinder arrangement: inline

• Number of valves: 8

• Compression ratio: 9.5:1

• Bore × stroke: 75 mm × 72 mm

• Ignition type: spark

• Injection type: Weber 34 LTA carburetor

• Maximum speed: 148 km/h

• 0 - 100km/h: 17,5 seconds
