Made in Australia
jpeg)
Dimension
- Mass:
- 11,400 kg (25,133 lb) (kerb)
- 15,400 kg (33,951 lb) (GVM)
- Length 7,180 mm
- Width 2,480 mm
- Height 2,650 mm
- Ground Clearance:
- 1,340 mm (Front Overhang)
- 1,950 mm (Rear Overhang)
- 40° (Approach Angle)
- 38° (Departure Angle)
- 108° (Ramp Over Angle)
- 60% (gradient)
- 36° (Side Slope)
- 460 mm (Vertical Obstacle)
- 1,200 mm (Fording, Unprepared)
Material
- Armour: Ballistic Exceeds STANAG 4569
Ballistic Up To STANAG 4569 level 3 – Option
FSP Up To STANAG 4569 Level 5 – Option
IED High Level Of Protection From Monocoque Hull – Standard Mine Exceeds STANAG 4569 Level 3 – Standard - Armament: Remote Weapon Station Up To 12.7mm HMG or 40mm AGM Launcher, or
Manned Open Turret Up To 12.7mm HMG or 40mm AGM Launcher
Propulsion
- Engine Model: Caterpillar 3126E 7.2L 6-Cylinder Diesel, Turbocharged 224 kW (300 hp) @ 2,200rpm / 1,166 N⋅m (860 lb⋅ft) @ 1,440 rpm
- Transmission: ZF 6HP502 ECOMAT G2 (6 Forward Speeds, 1 Reverse)
- Suspension: Arvin Meritorv 4000 Series Fully Independent, Progressive Coil Spring With Upper Control Arm And Lower Wishbone
Performance
- Max. Speed: 100 km/h
- Power/Weight: 26.4 hp/tonne
Other
- Steering System: Power Assisted
- Token: 0
- Tier: 2
- Driver Side: Right Side Drive
- Ingame Price: $200M
- Drive Train: 4WD
