🇩🇪 1995 BMW 850 CSi (E31)

STREnergy · April 14, 2020, 10:46am

Exterior (click to view)

Interior (click to view)

Blueprints (click to view)

Specifications:

Engine:

Engine Type: Naturally aspirated V12
Fuel Type: Gasoline
Displacement: 5,576 cubic centimetres (5.6 lites)
- Bore: 86 millimetres
- Stroke: 80 millimetres
Compression Ratio: 9.8:1
Engine Layout: Front-mounted engine, rear-wheel drive
Transmission Type: 6-speed manual transmission
- Gear Ratios:
  - Reverse: 3.89
  - 1st Gear: 4.25
  - 2nd Gear: 2.53
  - 3rd Gear: 1.68
  - 4th Gear: 1.24
  - 5th Gear: 1
  - 6th Gear: 0.83
- Final Drive: 2.93

Performance Figures:

Peak Power 375 horsepower, at 5,300 RPM
Peak Torque: 550 newton-metres of torque, at 4,000 RPM
RPM Limit: 5,800 RPM
Power to Weight: 201.07 horsepower per metric tonne
0-60 mph (0-97 km/h): 5.7 seconds
- 1/4 mile time: 13.3 seconds
- 0-1 km: 25.5 seconds
Top Speed: electronically limited to 155 mph (250 km/h)

Dimensions:

Body Style: 2-door coupe
Length: 4,780 millimetres
Width: 1,855 millimetres
Height: 1,330 millimetres
Wheelbase: 2,684 millimetres
Front Tread: 1,554 millimetres
Rear Tread: 1,562 millimetres
Curb Weight: 1,865 kilograms
Front Tires: 235/45 R17
Rear Tires: 265/40 R17

CC2 Stats:

Fictional Name: BWN 580EX
Derby Tier: 1
Pricing: $900k-$2M
Exclusivity: None
Acceleration: 10
Handling: 11.8
Braking: 12.2
Race Class: 68
Attack Score: 51
Defence Score: 91

Flamin_Cheetos · May 22, 2021, 11:40am

Cool

VVgamer135 · July 26, 2021, 8:19pm

Welp I accidentally made a thread, not knowing this one existed. My old thread content is below, but it’s probably not necessary anymore. This thread seems more complete than mine

old thread post

NAME: 1995 BMW 850CSI (E21) [any year from 1992-1996 works]

PICTURES:

Blueprint image: BMW 850 CSi E31 vector drawing

Specs i could find:

Engine Type: 60 degree V12
Fuel Type: gasoline (yes im from freedom land)
Displacement: 5,576 cubic centimetres (5.6L litres)
- Bore: 86 millimetres
- Stroke: 80 millimetres
Compression Ratio: 9.8:1
Engine Layout: Front Engine RWD
Transmission Type: Manual (only option)
- Gear Ratios: 6
  (couldn’t find any data for ratios)

Performance Figures:

Peak Power: 375 HP @ 5300 rpm
Peak Torque: 405 lbs/ft @ 4000 rpm
RPM Limit: 6,400 RPM
Power to Weight: 4.9 kg/hp
0-60 mph (0-97 km/h): 5.9 sec
- 1/4 mile time: 14.9 sec @ 108.7 mph
- 0-1 km: 25.5 sec
Claimed Top Speed: 155 MPH
Estimated Top Speed: 186 MPH
