FSC Żuk A-16B

––––––––––––––––––––––––––––––––––––

▶️ 1. Main ◀️

• Class: LCV

• Body type: 3-door dual cab pickup

• Transmision: 4-speed automatic

• Drivetrain: RWD

• Length: 4450 mm

• Width: 1875 mm

• Height: 2220 mm

• Wheelbase: 2700 mm

• Front track: 1365 mm

• Rear track: 1372 mm

• Tire size: 165/80 R16

• Rim size: 4.50 x 16

• Front brake type: drum

• Rear brake type: drum

• Front suspension type: independent, based on two wishbones, coil springs, and telescopic shock absorbers

• Rear suspension type: dependent, based on a rigid drive axle suspended on 13-leaf longitudinal springs

• Own weight: 1550 kg

• Number of seats: 6

––––––––––––––––––––––––––––––––––––

▶️ 2. Engine ◀️

• Model: 4C90

• Produced: from 1988 to 1998

• Displacement: 2417 cm³

• Engine type: 4-stroke diesel

• Engine power: 70 hp (51 kW) at 4200 rpm

• Maximum torque: 146 Nm at 2500 rpm

• Engine mounting: at the front, longitudinally

• Position of the camshaft: SOHC

• Number of cylinders: 4

• Cylinder arrangement: inline

• Number of valves: 8

• Compression ratio: 20,6: 1

• Bore x stroke: 90 mm x 95 mm

• Injection type: indirect

• Ignition type: compression

• Maximum speed: 95 km/h

• Engine code: 4C90
